Aluminum rod induction heating furnace

       Aluminum rod induction heating furnaceIt is a device specially used for heating aluminum rods. It uses the principle of induction heating by generatingWeak magnetic field and large currentto heat the aluminum rod. It is suitable for heating aluminum rods of various specifications, especially the heating process before forging/extrusion of aluminum rods. The maximum heating temperature is 650℃ and the rated operating temperature is 550℃, ensuring continuous and even heat penetration of aluminum rods before forging/extrusion. Due to the non-magnetic properties of the metal aluminum rod,Aluminum rod induction heating furnaceThe design and manufacturing are different from carbon steel and alloy steel induction heating. The unique design can ensure the smooth heating of aluminum rods and is environmentally friendly and energy-saving. under.Haishan electric furnaceThe editor will introduce thisAluminum rod induction heating furnacedetailed technical parameters.

one,Aluminum rod induction heating furnaceParameters:

1. Equipment name: KGPS-800kW/1.5kHzAluminum rod induction heating furnace

2. Equipment usage: used for heating aluminum alloy round bars

3. Equipment standards: comply with aluminum rod heating process parameters

4. Main process parameters and technical requirements of the equipment:

4.1. Blank material: aluminum alloy bar

4.2. Blank specification range: diameter 20mm--320mm, length 100mm--12000mm

4.3. Heating temperature: 350～580℃

4.4. Beat: 3~60 seconds/piece

4.5. Heating is stable during normal operation, and the temperature fluctuation between each section of material is within ±15°C; axial and radial (core meter) ≤20°C

4.6. The cooling water supply system pressure is greater than 0.3MPa (normal water pressure is greater than 0.2MPa), and the high temperature is 60°C. The corresponding hose pressure and interfaces also need to be increased to safety standards in proportion.

two,Aluminum rod induction heating furnacespecialty:

1. High efficiency and energy saving: The principle of induction heating makes the aluminum rod have high heating efficiency and high energy conversion efficiency, which is more energy-saving than traditional heating methods.

2. Uniform heating: Induction heating can heat the surface and interior of the aluminum rod at the same time, heating evenly, avoiding local overheating or underheating that may occur with traditional heating methods.

3. High degree of automation:Aluminum rod induction heating furnaceUsually equipped with an automated control system, which can realize functions such as automatic temperature control, automatic feeding and discharging, etc., greatly improving production efficiency.

4. Environmental protection and safety:Aluminum rod induction heating furnaceThe non-contact heating method avoids pollution problems such as harmful gases and dust that may be generated by traditional heating methods. At the same time, the equipment structure is simple, safe and reliable.

     5、Aluminum rod induction heating furnaceIt is widely used in the production, processing and heat treatment of aluminum rods. It can be used in the smelting, casting, rolling, annealing, quenching and other processes of aluminum rods, improving the production efficiency and product quality of aluminum rods.

If anyAluminum rod induction heating furnaceFor needs, please call Manager Guo at 13891812360; moreAluminum rod induction heating furnaceFor information, please follow the website of Shaanxi Haishan Mechanical and Electrical Co., Ltd. http://www.hszpl.com
